Ali-Craft Explorer 16 -18ft
Dimensions
| Length |
18' |
| Beam |
7'6" |
| Width Across Chine |
70" |
| Degree of Vee |
8,10,12 degree |
Standard Hull Details
| Bottom |
1/4" |
5086 High Tensile Aluminum |
| Sides |
1/8" |
5086 High Tensile Aluminum |
| Transom |
3/16" |
5086 High Tensile Aluminum |
| Deck Sheet |
1/8" |
5052 High Tensile Aluminum |
| Gunwale |
1-1/4" x 1-1/4" |
6061 Square Tube |
| Keel Stripe |
3/8" |
6061 Aluminum |
| Floor |
1/2" Plywood |
Covered with Vinyl |
| Windshield |
Tinted Glass |
Walkthrough |
| Side Trays & Panels |
16g |
Aluminum (vinyl covered) |
| Fuel Tanks |
2 x 19 (US) Gallon |
Molded Plastic |
| Stringers |
1/4" |
5052 Aluminum |
|
 |
Ali-Craft Caribou 16 -18ft
Dimensions
| Length |
18' |
| Beam |
7' |
| Width Across Chine |
6"5" |
| Degree of Vee |
8,10,12 degree (this can be altered) |
Standard Hull Details
| Bottom |
3/16" |
5086 High Tensile Aluminum |
| Sides |
1/8" |
5086 High Tensile Aluminum |
| Transom |
3/16" |
5086 High Tensile Aluminum |
| Deck Sheet |
1/8" |
5052 High Tensile Aluminum |
| Gunwale |
1-1/4" x 1-1/4" |
Square Tube |
| Keel Stripe |
1/4" |
5086 Aluminum |
| Floor |
1/2" Plywood |
Covered with Vinyl |
| Windshield |
|
Walkthrough an Option |
| Side Trays & Panels |
16g |
Aluminum (vinyl covered) |
|
 |
Ali-Craft Ranger 20 - 22ft
Dimensions
| Length |
22' |
| Beam |
8' |
| Width Across Chine |
6'3" |
| Degree of Vee |
8,10,12 degree (this can be altered) |
Standard Hull Details
| Bottom |
1/4" |
5086 High Tensile Aluminum |
| Sides |
1/8" |
5086 High Tensile Aluminum |
| Transom |
3/16" |
5086 High Tensile Aluminum |
| Deck Sheet |
1/8" |
5052 High Tensile Aluminum |
| Gunwale |
1-1/4" x 1-1/4" |
6061 Square Tube |
| Keel Stripe |
3/8" |
6061 Aluminum |
| Floor |
1/2" Plywood |
Covered with Vinyl |
| Windshield |
Tinted Glass |
Walkthrough |
| Side Trays & Panels |
16g |
Aluminum (vinyl covered) |
| Fuel Tanks |
2 x (US) Gallon |
Molded Plastic |
| Stringers |
1/4" Plate x 4 |
5052 Aluminum |
|
